• High quality imaging with 2 MP resolution
• Excellent low-light performance
• Efficient H.265+ compression technology
• Water and dust resistant (IP67)
• 24/7 colorful imaging

Specifications:

Camera

Image Sensor1/2.8″ Progressive Scan CMOS

Max. Resolution1920 × 1080

Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON)

Shutter Time1/3 s to 1/100,000 s

Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Focal Length & FOV

2.8mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127°

4mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99°

Lens MountM12

Iris TypeFixed

ApertureF1.0

Depth of Field

2.8 mm: 1.7 m to ∞

4 mm: 2.1 m to ∞

Lens TypeFixed focal lens, 2.8 and 4 mm optional

Illuminator

Supplement Light TypeWhite Light

Supplement Light RangeUp to 30 m

Smart Supplement LightYes

Video

Main Stream

50 Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

60 Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50 Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

60 Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264

Sub-stream: H.265/H.264/MJPEG

Video Bit Rate32 Kbps to 8 Mbps

H.264 TypeBaseLine Profile/Main Profile/High Profile

H.265 TypeMain Profile

Region of Interest (ROI)1 fixed region for main stream

Network

ProtocolsTCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS

Simultaneous Live ViewUp to 6 channels

APIONVIF (PROFILE S, PROFILE G), ISAPI, SDK

User/HostUp to 32 users. 3 user levels: administrator, operator and user

SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF

ClientiVMS-4200, Hik-Connect, Hik-Central

Web Browser

Plug-in required live view: IE8, IE9, IE10, IE11

Local service: Chrome 57.0+, Firefox 52.0+


Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Day/Night SwitchDay, Night, Auto, Schedule

Wide Dynamic Range (WDR)Digital WDR

Image EnhancementBLC, HLC, 3D DNR

Interface

Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port

Event

Basic EventMotion detection, exception (illegal login)

Linkage

Upload to FTP, notify surveillance center, send email, trigger recording, trigger capture

*Note: External device is required.

General

Power

12 VDC ± 25%, 0.30 A, max. 3.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection

PoE: 802.3af, Type 1 Class 3, 36 V to 57 V, 0.20 A to 0.10 A, max. 4.5W

Dimension68.4 × 65.2 × 161.1 mm (2.7″ × 2.6″ × 6.3″)

Package Dimension172 × 104 × 80 mm (6.8″ × 4.1″ × 3.1″)

Approx. 420 g (0.9 lb.)

With Package WeightApprox. 510g (1.1 lb.)

Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

LanguageEnglish

General FunctionAnti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter

Approval

EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)

EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

ProtectionIngression protection: IP67 (IEC 60529-2013)
